The N1 Evolution Extreme is based on the proven performance basics of the N1 muffler which emphasizes optimum exhaust efficiency utilizing a straight-thru layout design. Equipped with an internal hybrid silencer uniting power and free flowing characteristics with effective functional sound resonance. A newly adopted muffler tip completes the tail end of the exhaust that serves both purposes of function and form. Constructed with a light weight titanium material rolled and riveted onto a double pipe structure which acts as a diffuser enabling temperature reduction, meanwhile retaining a sporty heat gradiation appearance.
PRODUCT FEATURES:
- High-level of quality using tig-welded SUS304 stainless steel uniting quiet performance with high-power performance gains
- Matched and manufactured for select chassis
- Patented Megaphone piping structure to produce excellent torque and throttle response throughout the powerband. This piping design allows for a swirling exhaust gas flow effect that has for years produced proven results
Bolt-On | Yes |
---|---|
Part Number | 164-KT15 |
Year | 2019 |
Make | Toyota |
Model | Corolla Hatchback |
Body Style | 5-Door Hatchback |
Engine | M20A-FXS |
Chassis | MZEAZ12 |
Exhaust Type | N1 Evolution Extreme Muffler (N1-X) |
Piping Diameter | 50mm. - 50mm. x 2 - 50mm. x 4 |
Tip Diameter | 75mm. x 4 |
Pieces | 2 |
Exhaust Tip Style | Titanium Round- Dual wall rolled, Angle cut (Riveted) |
Piping Material | SUS304 Stainless Steel |
Muffler Material | SUS304 Stainless Steel |
Muffler Tip Material | Titanium |
System Weight | 31.75 lbs. |
Special Notes | Package Dimension: 59" x 12" x 20", Package Weight: 45 lbs. |
